CU-SOLO

Carbonite Ultra Solo All In One Production switcher

Feature Set:

MultiDefinition Operation Format Support:
-720p50/59.94, 1080i50/59.94
-1080pSF 23.98/24/25/29.97/30
-1080p23.98/24/25/29.97/30/50/59.94/60
-2160p23.98/24/25/29.97/30/50/59.94/60
-12 Inputs and 5 Configurable Outputs (Including MV Output)
-1 USB-C UVC Configurable Webcam Output (HD Only - Not in Release v1)
-1 Reference Input and 1 Reference Output, BB/TLS and H/V Adjustments
-1 MultiViewer with access to all Inputs, Outputs and Internal Buses. Up to 16 Windows with 49 Layouts to chose from. Up to 10 Timers in the
system Viewable on Timeclock overlay.
-1 ME with 6 Keyers plus a Transition Keyer
-2 MiniME with 2 Full Keyers and Preview
-4 MediaStores with Video and Alpha. Audio on Channel 1&2, 6 GB Total RAM Cache loading from USB user supplied storage
-GPU based h.264 Clip Player. Decode Files up to 1080p60 (Assign FSFC when in UHD), Streams files directly from USB user supplied storage
-4 Channels of DVE in HD or 2 Channels in UHD
-6 Input Frame Sync / Format Converters, Assignable to any of the 12 Inputs in HD or UHD
-5 Output Format Converters in HD (1 per Output) or 2 Assignable in UHD
-6 Input Proc Amp, Colour Corrector and SDR/HDR conversion. Assignable to Inputs - HD ONLY
-5 Output Proc Amp, Colour Corrector and SDR/HDR conversion. HD ONLY
-48 Fader (Stereo or Mono) RAVE Audio Mixer. Any Input Embedded pair/mono ch selectable on each Fader. 14 Stereo Mixers Including Main,
Monitor and 12 Aux Mix. Each Fader has 4 Band Parametric EQ, Compressor Limiter and Noise Gate. Audio Follow Video with Multi Source
Assignment linking.
-DashBoard Menu System and Virtual Panel
-Carbonite Device Controls - AMP, RossTalk, PBUS, Serial-VISCA over IP, Cambot/Furio, Yamaha Serial Midi (DM1000/01V96), TSL v3.1/5.0
and GVG 100 Editor Control. Note Additional PTZ brands accessible via DashBoard Robotics Gateway (see Gateway list for updated support list)
-LiveEDL for "Live to Tape" events with quick turn around edit workflows (currently no external LTC input method. All EDLs start with ZERO
based timecode)
-24 GPIO (individually assignable as Input or Output)
-24 Tally
-AES Output, Assignable to MediaStore, Clip Player or any RAVE Audio Mix
-10 Bit Video Processing in All Video Formats
-Single Brick(CUF-PSU), Dual Brick(CUF-PSU x 2) and Rack Mount Redundant Power(CUF-RACKPWR) are not included.
-24/7 Phone Support
-Includes XPression Live CG
