Custom_10309

Technical Parameter -
Pixel Pitch : 1.56mm
LED Type : Flip Chip COB
Graphics Card : Novastar A8s-N
Brightness (nit) : 800
Refresh Rate (Hz) : 7680

Resolution -
Resolution Width (pixels) : 2400
Resolution Height (pixels) : 864

Size / Weight -
Width (ft) : 12.30
Height (ft) : 4.43
Width (in) : 147 20/31
Height (in) : 53 7/46
Panel Depth (in) : 1 3/10
Width (mm) : 3750
Height (mm) : 1350
Panel Depth (mm) : 33
Weight (lbs) : 251

Panel Count -
600mm x 337.5mm : 20
450mm x 337.5mm : 4
300mm x 337.5mm : 4

Power Estimate -
Max Power (watts) : 1650
Avg Power (watts) : 552
Max. 20amp/ 110 Circuits : 1
Max. 20amp/ 208 Circuits : 1
110V Standard - 208V Upon Request with PO
Max. BTU/h (est.) : 3754
Avg. BTU/h (est.) : 1255

Data Estimate -
CATxx Runs to Wall - Primary Signal: 4

Wall Mount & Trim Kit Included
Power & Data Cables Included
Service Tool Included

Spares 10%
Modules : 20
Core Kit ( Hub, Graphics Card, PSU ) : 3

Novastar H2
4xHDMI input card
Fiber sender card
