Custom_7066

Technical Parameter
Pixel Pitch : 2.5
LED Type : SMD 3in1 1515
Graphics Card : Nova. A10S Pro
Brightness (nit) : 800
Refresh Rate : ≥3840

Resolution
Resolution Width (pixels) : 1536
Resolution Height (pixels) : 864

Size / Weight
Width (ft) : 12.60
Height (ft) : 7.09
Width (in) : 151 13/69
Height (in) : 85 3/76
Panel Depth (in) : 1 1⁄8
Wall Depth with Wall Mount (in) : 1 7⁄8
Width (mm) : 3840
Height (mm) : 2160
Panel Depth (mm) : 28.5
Wall Depth with Wall Mount (mm) : 48.5
Weight (lbs) : 406

Panel Count
960mm x 540mm : 16

Power Estimate
Max Power (watts) : 3733
Avg Power (watts) : 1244
Max. 20amp/ 110 Circuits : 2
Max. 20amp/ 208 Circuits : 1
110V Standard - 208V Upon Request with PO
Max. BTU/h (est.) : 8490
Avg. BTU/h (est.) : 2830

Data Estimate
CATxx Runs to Wall - Primary Signal: 4

3% Spares
Modules : 4

Hanging Bars for mounting from the ceiling
