Custom_7295

Technical Parameter
Pixel Pitch : 3.75
LED Type : SMD 3in1 1515
Graphics Card : Nova. A10S Pro
Brightness (nit) : 800
Refresh Rate : ≥3840

Resolution
Resolution Width (pixels) : 5504
Resolution Height (pixels) : 1872

Size / Weight
Width (ft) : 67.72
Height (ft) : 23.03
Width (in) : 812 37/58
Height (in) : 276 31/82
Panel Depth (in) : 1 1⁄8
Wall Depth with Wall Mount (in) : 1 7⁄8
Width (mm) : 20640
Height (mm) : 7020
Panel Depth (mm) : 28.5
Wall Depth with Wall Mount (mm) : 48.5
Weight (lbs) : 7065

Panel Count
960mm x 540mm : 273
480mm x 540mm : 13

Power Estimate
Max Power (watts) : 69551
Avg Power (watts) : 23184
Max. 20amp/ 110 Circuits : 33
Max. 20amp/ 208 Circuits : 19
110V Standard - 208V Upon Request with PO
Max. BTU/h (est.) : 158192
Avg. BTU/h (est.) : 52731

Data Estimate
CATxx Runs to Wall - Primary Signal: 17

3% Spares
Modules : 67
Core Kit ( Hub, Graphics Card, PSU ) : 9

Wall mount system/Trim kit
H2Video Wall Splicer
4xHDMI input card
2x Fiber sender card
Freight included
