Custom_8189

Technical Parameter
Pixel Pitch : 2.5
LED Type : SMD 3in1 1515
Graphics Card : Nova. A10S Pro
Brightness (nit) : 800
Refresh Rate : ≥3840

Resolution
Resolution Width (pixels) : 1728
Resolution Height (pixels) : 972

Size / Weight
Width (ft) : 14.17
Height (ft) : 7.97
Width (in) : 170 2/23
Height (in) : 95 2/3
Panel Depth (in) : 1 1⁄8
Wall Depth with Wall Mount (in) : 1 7⁄8
Width (mm) : 4320
Height (mm) : 2430
Panel Depth (mm) : 28.5
Wall Depth with Wall Mount (mm) : 48.5
Weight (lbs) : 500

Panel Count
960mm x 540mm : 16
480mm x 540mm : 4
480mm x 270mm : 1
960mm x 270mm : 4

Power Estimate
Max Power (watts) : 4724
Avg Power (watts) : 1575
Max. 20amp/ 110 Circuits : 3
Max. 20amp/ 208 Circuits : 2
110V Standard - 208V Upon Request with PO
Max. BTU/h (est.) : 10745
Avg. BTU/h (est.) : 3582

Data Estimate
CATxx Runs to Wall - Primary Signal: 5
Wall Mount & Trim Kit Included
Power & Data Cables Included
Service Tool Included

Spares 5%
Modules : 8
Core Kit ( Hub, Graphics Card, PSU ) : 1
Novastar MX20
