Custom Quote: #111464.0.0
I. Power Control Devices to consist of:
A. Unison Echo Relay Panel to consist of:
QTY: 1 - 7123A1022. ERP-24R1-24B1-ML3P - Unison Echo Relay Panel with:
Painted Steel Enclosure (no door)
120/208V three-phase main lug input
24-space relay sub-panel (24 installed one pole relays)
30-space breaker sub-panel (24 installed one pole breakers)
Breaker sub-panel includes 1 installed one pole breaker for control electronics
Integral control processor with 1 DMX input & 1 Network input
UL924-listed control bypass input
3 option card spaces.
QTY: 1 - 7123A1701. ERP-SMD - Unison Echo Relay Panel Surface Mount Door Front panel and door assembly with no overhang for 120V ERP.
QTY: 1 - 7123K1005. ERP-200A-3P 22kA MCB - Unison Echo Relay Panel Main Circuit Breaker option kit - 120/208V 3 pole 200A breaker with 22kA SCCR rating.
B. Foundry Power Controllers to consist of:
QTY: 3 - 7179A1024. UFR2 - Foundry Dual Channel Relay Controller to include:
- 120-277VAC, 20A power input
- 1/2"" conduit knockout mountable
- DMX control input
- Two fully rated 20 Amp relay output
Note: Bussing between racks is not included.
Note: This power system is designed for 1 feed at a maximum of 200A.
II. Distribution Devices to consist of:
A. Connector Strips to consist of:
QTY: 2 - QUOTE-30061. 9915-2AD-5B - Connector strip 15'-0” long with:
5 – Panel mount 20A Stage Pin (2P&G/GPC) connectors wired on 5 - 20A circuits
2 – Panel mount 20A Edison Duplex (5-20RD) connectors wired on 2 - 20A circuits
4 – Hanging Brackets
QTY: 1 - QUOTE-30061. 9922-4AD/2-8B - Connector strip 22'-0” long with:
8 – Panel mount 20A Stage Pin (2P&G/GPC) connectors wired on 8 - 20A circuits
4 – Panel mount 20A Edison Duplex (5-20RD) connectors wired on 2 - 20A circuits
6 – Hanging Brackets
QTY: 1 - QUOTE-30061. 9938-8AD/4-20B - Connector strip 38'-0” long with:
20 – Panel mount 20A Stage Pin (2P&G/GPC) connectors wired on 20 - 20A circuits
8 – Panel mount 20A Edison Duplex (5-20RD) connectors wired on 4 - 20A circuits
9 – Hanging Brackets
QTY: 3 - QUOTE-30061. 9938-8AD/4-8B - Connector strip 38'-0” long with:
8 – Panel mount 20A Stage Pin (2P&G/GPC) connectors wired on 8 - 20A circuits
8 – Panel mount 20A Edison Duplex (5-20RD) connectors wired on 4 - 20A circuits
9 – Hanging Brackets
B. Outlet Boxes to consist of:
QTY: 2 - CUSTOM ITEM. 9201AD-2B - Custom Sized Flush Outlet plate with:
1 – panel mount 20A Edison Duplex (5-20RD) connectors wired on 1 - 20A circuits
2 – panel mount 20A Stage Pin (2P&G/GPC) connectors wired on 2 - 20A circuits
III. Architectural Control Devices to consist of:
A. DIN Enclosure to consist of:
QTY: 1 - 7180K1018-H. DIN28 - Large enclosure with (1) 13" piece of horizontal DIN rail and (2) 27" pieces of vertical DIN rail space and a repositionable voltage barrier. Box exterior size is 14" x 36" x 5"
QTY: 1 - 7180K1011. DIN28 ACCKIT - DIN28 Install Kit
Contains 10’ of wire (one Blk/Red twisted pair, one Blk/Wht twisted pair, and one ground), 2’ of DMX wire, 10x 5 position Wago’s, 4x Cat5 term kit, 4x Cat5 patch cable, and 8x end stop
QTY: 1 - 4267A1231. RSN-OPTO-8DIN - Response Opto-Splitter
8 Terminal Output Ports
1 In and 1 Thru Ports
DIN rail mounted
QTY: 1 - 7186A1232. E-SPS-DIN Mk2 - Echo DIN-mount Station Power Supply to include:
100-240VAC Power Input
Support for 16 Echo Control Devices
Support for 16 Echo Output Devices
Provides 24VDC 2A Aux power
QTY: 1 - 7186A1233. E-APS2 - Echo Auxiliary Power Supply Mk2 to include: - 100-277VAC Power Input - 1/2" Conduit Knockout Mountable - Provides 24VDC Auxiliary Power
QTY: 1 - 7186A1131. EDMXC - Unison Echo DMX Scene Controller with:
- DMX Input for scene snapshot and live control
- DMX output for up to 512 channels
- EchoConnect Interface
- Requires 24VDC Auxiliary Power
B. Echo Inspire Button Stations and Extra Faceplates to consist of:
QTY: 4 - 7186A1002-4. E1002-4 - Echo Inspire Button Station (Black) to include:
- 2-button electronics assembly
- Single gang decorator faceplate
- Button label sheet
- Installation hardware
QTY: 4 - 7186A2010-4. IFPB-4 - 1 Gang blank plate for Inspire stations. Includes mounting hardware. Black
QTY: 4 7186A2102-4. 2IFP-4 - 2-Gang Inspire Class 2 Faceplate - Black
C. Echo Touchscreens to consist of:
QTY: 1 - 7186A1119-4. ETS-4 - Unison EchoTouch Mk2 Controller with black finish to include:
- 7-inch LCD Touchscreen
- 80 Channels
- Support for 16 Unison Echo control zones per space
- Support for 512 DMX, sACN , or ArtNet outputs
- Built-in TimeClock with support for 80 Events
- PoE or 24vDC power input (power supply not included)
IV. Control Devices to consist of:
A. Control Plug-in Boxes to consist of:
QTY: 1 - CUSTOM ITEM. ECPB N/N/X - Custom Sized DMX Input / Net / Net Control Plug-in Station with:
1 - XLR-5MDM3 DMX In Connector(s)
2 - RJ-45 (568B) Connector in XLR case with voltage barrier
QTY: 1 - CUSTOM ITEM. ECPB N/N/X - Custom Sized DMX Output / Net / Net Control Plug-in Station with:
1 - XLR-5FDM3 DMX Out Connector(s)
2 - RJ-45 (568B) Connector in XLR case
with voltage barrier.
