UpadIV3.9-PI-07351

UpadIV 3.9

Cabinet Configuration 20 x 10 (Feet 32.81 x 16.40)

Meters 10.00 x 5.00

Resolution 2,560 x 1,280

Weight 2,778 lbs 1,260 kg

Max Power 24,000 W 67,560 BTU
Typical Power 8,000 W 22,520 BTU

Screen Diagonal (inches) 440.17"

Minimum 120VAC 20A Circuits 15

Aspect Ratio 2.00

Display QTY 1

Data Cables Needed 16




Section 1: UpadIV

Total Pixels 3,276,800

Cabinet Quantity 200

Module Quantity 800

Module Size 250mm x 250mm (9.84in x 9.84in)

Cabinet Size 500mm x 500mm (20in x 20in)

Brightness (nits) 1000

LED Lamp SMD2121

Warranty 2 Years

Service Front/Rear

15 Spare Modules



Section 2: Control System
x1 NovaPro UHD Jr. LED Controllers



Section 3: Accessories
1x Pallet Case For modules and cabinets

1x Hanging Bars with Eye Hook or Truss Clamp

1x Floor Stand with supports (cannot exceed 6 meters)



Section 4: Installation
Standard onsite installation support
Onsite certification



Section 5: Spare Parts
984x LED Packages
159x Driver IC
99x Module masking
10x Modules
10x Power supplies
10x Power input cables
10x Signal Input Cables
10x Receiving Car
10x Hub Card
10x Data Uploading Pinboard
10x Power and Signal Pinboard
